- It would be: Spark Series
- Resolution: 2688 x 1520, 2560 x 1440, 2304 x 1296, 1920 x 1080; Transducer: 1/3"
- Viewing angle: 92°
- IR illuminator range: 30 m
- Image compression method: S+265
- Audio: Built-in microphone
- Power supply: PoE (802.3af)
KAMERA IP TC-C34QN SPEC:I3/E/Y/2.8MM/V5.0 Spark Series - 4 Mpx 2.8 mm TIANDY
€579.86
Tax included
- It would be: Spark Series
- Resolution: 2688 x 1520, 2560 x 1440, 2304 x 1296, 1920 x 1080; Transducer: 1/3"
- Viewing angle: 92°
- IR illuminator range: 30 m
- Image compression method: S+265
- Audio: Built-in microphone
- Power supply: PoE (802.3af)
Security policy
(edit with the Customer Reassurance module)
Delivery policy
(edit with the Customer Reassurance module)
Return policy
(edit with the Customer Reassurance module)
PoE power supply option in accordance with the 802.3af standard makes the device even more universal and easier to install
The range of the illuminator provided by the manufacturer depends on the environmental conditions (air transparency, surroundings, wall color, i.e. the so-called scene reflectance)
Attention!
Enabling the ONVIF protocol in the camera disables P2P access
| He would be: | Spark Series |
| Standard: | IP |
| Resolution: | 2688 x 1520 - 4 Mpx , 2560 x 1440 - 3.7 Mpx , 2304 x 1296 - 3 Mpx , 1920 x 1080 - 1080p , 1280 x 720 - 720p |
| Converter: | 1/3 " Progressive Scan CMOS |
| Lens: | 2.8 mm |
| Viewing Angle: | 92 ° |
| IR illuminator range: | 30 m |
| Memory card slot: | NO |
| Image compression method: | S+265 / H.265 / H.264 |
| Alarm inputs/outputs: | NO |
| Audio: |
|
| Main stream transmission speed: | 20 kl/s @ 4 Mpx |
| Interface: | 10/100 Base-TX (RJ-45) |
| WEB Server: | Built-in |
| Max. number of online users: | 2 |
| ONVIF: | NO |
| Mobile phone access: | Port: 3000 or cloud access (P2P)
|
| Access from PC: | Port: 3000 or cloud access (P2P) - PC: Free applicationEasy7 Smart Client Express |
| Default IP address: | DHCP the 192.168.1.2 |
| Default administrator login/password: | admin / - An administrator password must be set at first startup |
| Web access ports: | 80, 3000, 3001 |
| Access port via mobile application: | 3000, 3001 |
| Access ports via PC application: | 3000, 3001 |
| Port ONVIF: | 80 |
| Intelligent face analysis: | NO |
| Selected features: |
|
| Power supply: | People (802.3AF) |
| Power consumption: | ≤ 6 W |
| Case: | Compact - Metal + Plastik |
| Color: | White |
| Tightness class: | IP67 |
| Mechanical protection class: | NO |
| Operating temperature: | -30 °C ... 60 °C |
| Libra: | 0.21 kg |
| Dimensions: | 164 x 73 x 73 mm |
| Supported languages: | Polish, English, Albanian, Arabic, Spanish, Korean, French, Dutch, Hebrew, German, Portuguese, Russian, Thai, Turkish, Ukrainian, Vietnamese, Italian |
| Manufacturer / Brand: | TIANDY |
| Guarantee: | 3 lata |
