SPEED OUTDOOR IP CAMERA TC-H326S SPEC:33X/I/E+/A/V3.0 - 1080p 4.6 ... 152 mm TIANDY

SPEED OUTDOOR IP CAMERA TC-H326S SPEC:33X/I/E+/A/V3.0 - 1080p 4.6 ... 152 mm TIANDY

€6,463.22
Tax included
  • Transducer: 1/2.8"
  • Matrix size: 2 Mpx
  • Resolution: 1920 x 1080; Viewing angle: 60° ... 2.3°
  • Optical zoom: x 33; IR illuminator range: 200 m
  • Rotation speed (manual control): 0.1°/s ... 180°/s (horizontal) 0.1°/s ... 120°/s (vertical)
  • Image compression method: S+265
  • Alarm inputs/outputs: 1 / 1; Memory card slot: Supports Micro SD cards up to 512GB
  • Power supply: PoE (802.3at), 12 V DC
Quantity
Add to Wishlist
Add to Compare

  Security policy

(edit with the Customer Reassurance module)

  Delivery policy

(edit with the Customer Reassurance module)

  Return policy

(edit with the Customer Reassurance module)

IP camera with a very good, high resolution sensor

This makes it ideal for monitoring systems where identification of people or vehicles is required

The built-in infrared illuminator allows you to work at night, and the varifocal lens with a wide range of viewing angle adjustment allows for optimal image framing in all conditions.

The range of the illuminator provided by the manufacturer depends on the environmental conditions (air transparency, surroundings, wall color, i.e. the so-called scene reflectance)

PoE power supply option in accordance with the 802.3at standard makes the device even more universal and easier to install

For several IP cameras operating at resolution ≥ 1920 x 1080, we recommend using a network with a bandwidth of 1Gb/s

Standard: IP
Converter: 1/2.8 " Progressive Scan CMOS
Matrix size: 2 Mpx
Resolution: 1920 x 1080 - 1080p ,
1280 x 720 720p
Lens: 4.6 ... 152 mm
Viewing Angle:
  • 60° ... 2.3° (manufacturer's data)
  • 57° ... 2.8° (our tests)
Optical zoom: x 33
Digital zoom: x 16
IR illuminator range: 200 m
Video output: NO
Rotational speed with presets:
  • 240°/s (horizontal)
  • 120 °/s (pion)
Rotational speed (manual control):
  • 0.1°/s ... 180°/s (horizontal)
  • 0.1 °/s ... 120 °/s (pion)
Horizontal rotation range: 360° - continuous
Vertical rotation range: -16 ° ... 90 °
Interface RS-485: NO
Number of presets: 500
Horizontal Scanning: NO
Set traffic routes: 8
Image compression method: S+265 / H.265 / H.264 / MJPEG
Alarm inputs/outputs: 1 / 1
Audio:
  • Audio input
  • Audio output
Main stream transmission speed: 25 kl/s @ 1080p
Network interface: 10/100 Base-T (RJ-45)
WEB Server: Built-in
ONVIF: NO
Memory card slot: Micro SD card support up to 512GB
Mobile phone access: Port: 3000 or cloud access (P2P)
Access from PC: Port: 3000 or cloud access (P2P) - PC: Free applicationEasy7 Smart Client Express
Max. number of online users: ≤ 7
Default IP address: 192.168.1.2
Default administrator login/password: admin / -
An administrator password must be set at first startup
Web access ports: 80, 443, 3000, 3001, 3002, 23002
Access port via mobile application: 3000, 3001
Access ports via PC application: 3000, 3001
Port ONVIF: 80
Intelligent face analysis:
  • classification of people and vehicles
  • crossing the line
  • double crossing the line
  • intrusion
  • abandoned/missing object
  • illegal parking
  • counting people
  • detection of gatherings of people
  • heat map
  • wandering detection in a given area
  • running
  • safety helmet detection
  • detection of people on duty
  • face detection
  • Intelligent object tracking
  • video sabotage
Selected features:
  • WDR - 120 dB - Wide dynamic range of lighting
  • 2D-DNR, 3D-DNR - Digital noise reduction in the image
  • ROI - improving the quality of selected image fragments
  • F-DNR (Defog) - Reduction of noise related to precipitation
  • ANR - image recording on the card when there is no connection with the recorder (network failure) and subsequent synchronization
  • BLC/HLC - background light/strong light compensation
  • Day/night mode
  • ICR - Mechanical infrared filter
  • Motion detection
  • Image rotation and mirroring
  • Adaptive adjustment of the IR illuminator power to the lens zoom and external lighting brightness
Power supply:
  • People (802.3at),
  • 12V DC
Power consumption: max. 24 W
Case: Speed Dome, Aluminium
Color: White + Black
Operating temperature: -30 °C ... 65 °C
Tightness class: IP66
Vandal-proof: NO
Libra: 5.3 kg
Dimensions: Ø 226 x 372 mm (without handle)
Supported languages: Polish, English, Albanian, Arabic, Spanish, Korean, Turkish, Russian, French, Dutch, Hebrew, German, Portuguese, Thai, Ukrainian, Vietnamese, Italian
Manufacturer / Brand: TIANDY
Guarantee: 3 lata
Tiandy
NS33499
1 Item

Data sheet

Protocol
BLE
CIP
GRE
LIN
ONVIF
PoE
RS-485
Voltage
12V
IP Class
IP66
Image compression method
H.264
H.265
MJPEG
