Resolution:3840 x 2160, 3072 x 2048, 3072 x 1728, 2880 x 1620, 2688 x 1520, 2048 x 1536, 2304 x 1296, 1920 x 1080;Sensor:1/2.7 ";View angle:110 °;Range of IR illumination:30 m;White light LED illuminator range:30 m;Image compression method:H.265+;Audio:Microphone built-in;Power supply:PoE (802.3af), 12 V DC;
IP CAMERA IPC-HFW1839TC-A-IL-0280B-S6 Smart Dual Light 8.3 Mpx 4K UHD 2.8 mm DAHUA
€376.13
Tax included
Resolution:3840 x 2160, 3072 x 2048, 3072 x 1728, 2880 x 1620, 2688 x 1520, 2048 x 1536, 2304 x 1296, 1920 x 1080;Sensor:1/2.7 ";View angle:110 °;Range of IR illumination:30 m;White light LED illuminator range:30 m;Image compression method:H.265+;Audio:Microphone built-in;Power supply:PoE (802.3af), 12 V DC;
Security policy
(edit with the Customer Reassurance module)
Delivery policy
(edit with the Customer Reassurance module)
Return policy
(edit with the Customer Reassurance module)
| Standard: | IP |
| Resolution: | 3840 x 2160 8.3Mpx 4K UHD, 3072 x 2048 - 6Mpx, 3072 x 1728 - 5.3Mpx, 2880 x 1620 - 4.7Mpx, 2688 x 1520 - 4Mpx, 2048 x 1536 - 3Mpx, 2304 x 1296 - 3Mpx, 1920 x 1080 -1080p, 1280 x 960 - 1.3Mpx, 1280 x 720 -720p |
| Sensor: | 1/2.7 " Progressive Scan CMOS |
| Lens: | 2.8 mm |
| View angle: | 110 ° |
| Range of IR illumination: | 30 m |
| White light LED illuminator range: | 30 m |
| S/N ratio: | 56dB |
| Memory card slot: | |
| Image compression method: | H.265+ /H.265/ H.264+ /H.264/MJPEG |
| Alarm inputs / outputs: | |
| Audio: | Microphone built-inAudio transmission via networkAudio detection |
| Main stream frame rate: | 20fps@ 8Mpx 25fps@ 4Mpx |
| Network interface: | 10/100 Base-T (RJ-45) |
| WEB Server: | Built-in |
| Max. number of on-line users: | 6 |
| ONVIF: | |
| Mobile phones support: | Port no.: 37777 or access by a cloud (P2P)Android:DMSSfree applicationiOS (iPhone):DMSSfree application |
| Default IP address: | 192.168.1.108 |
| Default admin user / password: | admin / - The administrator password should be set at the first start |
| Web browser access ports: | 80, 37777 |
| PC client access ports: | 37777 |
| Mobile client access ports: | 37777 |
| Port ONVIF: | 80 |
| RTSP URL: | rtsp://admin:hasło@192.168.1.108:554/cam/realmonitor?channel=1subtype=0 - Main stream rtsp://admin:hasło@192.168.1.108:554/cam/realmonitor?channel=1subtype=1 - Sub stream |
| Intelligent image analysis: | Human detection |
| Main features: | When Smart Dual Light is active, the white light will turn on automatically only when an object is detected in the monitored area, which effectively improves the image quality D-WDR - Wide Dynamic Range 3D-DNR - Digital Noise Reduction ROI - improve the quality of selected parts of image BLC/HLC - Back Light / High Light CompensationPossibility to change the resolution, quality and bit rateImage rotation and mirror Motion Detection - max. 4 configurable zones Privacy zones - max. 4 |
| Power supply: | People (802.3AF),12 VDC/ 290 mA |
| Power consumption: | ≤ 3.5 W @ 12 VDC ≤ 5.8 W @ |
| Housing: | Compact - Metal |
| Color: | White + Black |
| "Index of Protection": | IP67 |
| Mechanical protection class: | |
| Operation temp: | -40 °C ... 60 °C |
| Weight: | 0.44 kg |
| Dimensions: | 173 x 70 x 70 mm |
| Supported languages: | Polish, English, Czech, French, Spanish, Dutch, German, Russian, Portuguese, Romanian, Turkish, Ukrainian, Hungarian, Italian |
| Manufacturer / Brand: | DAHUA |
| Guarantee: | 3 years |
