DC/DC converter, voltage boost, Vin 10...30VDC, Vout 48VDC, Pout 100W, built-in module, ATTE type ASUC-100-480-OF
DC/DC converter ATTE ASUC-100-480-OF
€187.91
Tax included
DC/DC converter, voltage boost, Vin 10...30VDC, Vout 48VDC, Pout 100W, built-in module, ATTE type ASUC-100-480-OF
Security policy
(edit with the Customer Reassurance module)
Delivery policy
(edit with the Customer Reassurance module)
Return policy
(edit with the Customer Reassurance module)
Boost converter module
| Typ: | Voltage boost, DC/DC |
| Number of entries: | 1 |
| Number of outputs: | 2 |
| Supply voltage: | 10 ... 30 V DC |
| Output voltage: | 48 V DC |
| Output voltage regulation: | NO |
| Output current: | 2.5 A (max) |
| Moc: | 120 W (max) @ 24 V DC 80 W (max) @ 12 V DC |
| Security: | Protection against reverse polarity of the input voltage |
| Libra: | 0.037 kg |
| Dimensions: | 83 x 39 x 27 mm |
| Manufacturer / Brand: | ATTE |
| Guarantee: | 3 lata |
