IP Recorder TC-R3840 SPEC:I/B/N/V4.0 40 Channels TIANDY

IP Recorder TC-R3840 SPEC:I/B/N/V4.0 40 Channels TIANDY

€8,597.00
Tax included
  • Supported resolutions: max. 16 Mpx
  • Supported hard drives: 8 x 24 TB SATA + 1 x eSATA
  • Video outputs: 2 pcs HDMI 4K, 2 pcs VGA
  • Audio inputs/outputs: 1 / 1; Image compression method: S+265 / S+264
  • Alarm inputs/outputs: 16/4; Series: Pro
Quantity
Add to Wishlist
Add to Compare

  Security policy

(edit with the Customer Reassurance module)

  Delivery policy

(edit with the Customer Reassurance module)

  Return policy

(edit with the Customer Reassurance module)

The TC-R3840 SPEC:I/B/N/V4.0 Pro series digital recorder is a professional device used in IP monitoring installations.

Registration takes place in the H.265 / H.264 compression standard, which allows for obtaining the best image quality while using the minimum network bandwidth and disk capacity.

The menu has been designed in a way that makes it easy for anyone, even a novice user, to navigate and make changes to the recorder settings.

Supported standards: IP
Number of supported channels: 40
Supported resolutions: max. 16 Mpx
AI implemented by the recorder: NO
AI implemented by cameras:
  • crossing the line
  • double crossing the line
  • abandoned/missing object
  • wandering detection in a given area
  • running
  • parking detection
  • heat map
  • signal loss indication
  • License plate recognition
  • detection of people on duty
  • crowd detection
  • Parking monitoring mode
  • safety helmet detection
  • electric bike detection
  • counting people
  • Smoke detection, fire detection
  • Temperature measurement
  • advanced face capture features - Support for up to 300 face databases, including 100,000 face photos
  • Face recognition
  • Intelligent motion detection (distinguishing between people and vehicles)
Mobile phone access: Port: 3000 or cloud access (P2P)
Access from PC: Ports 80, 443, 3000, 3001, 3002, 23002
Supported hard drives:
  • 8 x 24 TB SATA + 1 x eSATA
  • Possibility of operating disks in a RAID JBOD/0/1/5/6/10 array
Video outputs:
  • 2 szt. HDMI 4K,
  • 2 pcs VGA
Bitrate: 640 Mbps (incoming)
Audio inputs/outputs: 1 / 1
Image compression method: S+265 / H.265 / S+264 / H.264
Archiving on external media: Archiving to a USB drive (pendrive, external drive), eSATA
Network interface: 2 x RJ-45 - 1 Gb/s
ONVIF: NO
Default IP address: 192.168.1.3
Default administrator login/password: admin / -
An administrator password must be set at first startup
USB:
  • 2 x USB 2.0
  • 1 x USB 3.0
Alarm inputs/outputs: 16 / 4
Switch PoE: NO
Power supply: 100 V ... 240 V AND
Power consumption: 18 W (bez HDD)
Working temperature: -10 °C ... 55 °C
Libra: 6.25 kg
Dimensions: 440 x 465 x 95 mm
Supported languages: Polish, English, Albanian, Arabic, Traditional Chinese, Simplified Chinese, French, Spanish, Korean, Dutch, Hebrew, Portuguese, German, Russian, Thai, Turkish, Ukrainian, Vietnamese, Italian
Manufacturer / Brand: TIANDY
He would be: Pro
Guarantee: 3 lata
Pro:
Tiandy
NS33544
1 Item

Data sheet

APP
Google home
Protocol
BLE
LIN
ONVIF
PoE
USB
Image compression method
H.264
H.265
