Akuvox R20K Single-family external panel, surface-mounted, Black

Video intercom thatenablesvisual and voice identification of people entering. It has2 built-inrelays allowing for control2 passes(two doors, a wicket and a gate, etc.),equippedwith Mifare and Unique RF card reader (13.56MHZ 125KHZ).

• Vandal-proof housing with numeric keypad
• Wide-angle camera with night mode
• 2 relay outputs/inputs
• Surface-mounted version
• Power supply via PoE
• Two-way audio communication with echo and noise reduction
• Compatible with the SIP protocol, possibility of cooperation with PBX switchboards and other SIP IP devices, configuration via a web browser, compliant with the ONVIF standard - integration with monitoring systems (CCTV)
• Aluminum housing, IP 65
• RF Card Reader: 13.56MHZ 125KHZ, Wiegand, Onvif

By connecting the system to the Internet, we can remotely operate the video intercom via a dedicated smartphone application. The smartphone can act as a video intercom monitor, providing the ability to answer calls, view and open the entrance from any place with Internet access.

• Front panel: IP 65 aluminum alloy
• Camera: 2Mpix, automatic backlight
• Numeric keyboard
• Relay inputs/outputs: 2
• Electronic list of tenants
• number of monitors within 1 premises: 8
• Displaying messages
• Light sensor
• Night lighting: infrared
• Port Wiegand: TAK
• Port RS485: SO
• RFID card reader: 13.56 MHz and 125 kHz
• Microphone: -40dB
• Speaker: 8Ω / 2W
• Output power: 12V/400mA
• Ethernet port: RJ45, 10/100 Mbps auto-negotiation Power-over-Ethernet 802.3af 12V DC connector (if not using PoE)
• Waterproof and dustproof: IP65
• Installation: Surface mounting
• Operating humidity: 10 ~ 90%
• Operating temperature: -20 °C ~ + 55 °C
• Storage temperature: -40 °C ~ + 70 °C

• SIP v1 (RFC2543), SIP v2 (RFC3261)
• Wąscopemowymody codek audio: G.711a, G.711μ, G.729
• Wideband audio codec: G.722
• DTMF: IN-BOUND, OUT-BOUND, DTMF (RFC2833), SIP Info
• Comfort: noise and echo reduction system

• Camera: 1/2.7”, CMOS
• Video resolution: CIF, QCIF, VGA, 4CIF, 720p,
• Video codec: H.264
• FPS: 30 at 720p
• Max. image transfer rate: 720p – 30 fps
• Viewing angle: 110°(H)/58°(V)
• Illumination with infrared diodes at night
• Sensitivity: 0.1 Lux

• Obsługa protokołów: IPv4, HTTP, HTTPS, FTP, SNMP, DNS, NTP, RTSP, RTP, TCP, UDP, ICMP, DHCP, ARP

• Relays individually controlled by DTMF tones
• The camera works in continuous mode
• Night mode with IR LED lighting
• White balance: automatic
• Minimum illumination: 0.1 LUX

The video intercom works with drives from leading manufacturers, e.g. Beninca, FAAC, Nice, Somfy. Opening the gate with a button directly from the video intercom monitor or a smartphone with an installed mobile application.
