Akuvox Panel R20K + Monitor S563W set

• Akuvox R20K IP outdoor panelx1
• 8" Akuvox S563W IP video intercom monitorx1

Video intercom thatenablesvisual and voice identification of people entering. It has2 built-inrelays allowing for control2 passes(two doors, a wicket and a gate, etc.),equippedwith Mifare and Unique RF card reader (13.56MHZ 125KHZ).

• Vandal-proof housing with numeric keypad
• Wide-angle camera with night mode
• 2 relay outputs/inputs
• Surface-mounted version
• Power supply via PoE
• Two-way audio communication with echo and noise reduction
• Compatible with the SIP protocol, possibility of cooperation with PBX switchboards and other SIP IP devices, configuration via a web browser, compliant with the ONVIF standard - integration with monitoring systems (CCTV)
• Aluminum housing, IP 65
• RF Card Reader: 13.56MHZ 125KHZ, Wiegand, Onvif

By connecting the system to the Internet, we can remotely operate the video intercom via a dedicated smartphone application. The smartphone can act as a video intercom monitor, providing the ability to answer calls, view and open the entrance from any place with Internet access. The price of the device includes activation of connections via the manufacturer's cloud. Operation can be performed on 4 Android/iOS smartphones. If you want to receive calls on more than 4 smartphones, you must purchase the activation of an additional account for the smartphone at one time directly from the application (max. 9 smartphones). No monthly subscription fees.

• Front panel: IP 65 aluminum alloy
• Camera: 2Mpix, automatic backlight
• Numeric keyboard
• Relay inputs/outputs: 2
• Electronic list of tenants
• number of monitors within 1 premises: 8
• Displaying messages
• Light sensor
• Night lighting: infrared
• Port Wiegand: TAK
• Port RS485: SO
• RFID card reader: 13.56 MHz and 125 kHz
• Microphone: -40dB
• Speaker: 8Ω / 2W
• Output power: 12V/400mA
• Ethernet port: RJ45, 10/100 Mbps auto-negotiation Power-over-Ethernet 802.3af 12V DC connector (if not using PoE)
• Waterproof and dustproof: IP65
• Installation: Surface mounting
• Operating humidity: 10 ~ 90%
• Operating temperature: -20 °C ~ + 55 °C
• Storage temperature: -40 °C ~ + 70 °C

• SIP v1 (RFC2543), SIP v2 (RFC3261)
• Wąscopemowymody codek audio: G.711a, G.711μ, G.729
• Wideband audio codec: G.722
• DTMF: IN-BOUND, OUT-BOUND, DTMF (RFC2833), SIP Info
• Comfort: noise and echo reduction system

• Camera: 1/2.7”, CMOS
• Video resolution: CIF, QCIF, VGA, 4CIF, 720p,
• Video codec: H.264
• FPS: 30 at 720p
• Max. image transfer rate: 720p – 30 fps
• Viewing angle: 110°(H)/58°(V)
• Illumination with infrared diodes at night
• Sensitivity: 0.1 Lux

• Obsługa protokołów: IPv4, HTTP, HTTPS, FTP, SNMP, DNS, NTP, RTSP, RTP, TCP, UDP, ICMP, DHCP, ARP

• Relays individually controlled by DTMF tones
• The camera works in continuous mode
• Night mode with IR LED lighting
• White balance: automatic
• Minimum illumination: 0.1 LUX

The video intercom works with drives from leading manufacturers, e.g. Beninca, FAAC, Nice, Somfy. Opening the gate with a button directly from the video intercom monitor or a smartphone with an installed mobile application.
