SMPS 12V buffer power supply, Vin 230VAC, Vout 10.2 ...13.8VDC, Iout 8A, Ich 1 / 2A, Pout 100W, built-in module, type AUPS-100-1

SMPS 12V buffer power supply, Vin 230VAC, Vout 10.2 ...13.8VDC, Iout 8A, Ich 1 / 2A, Pout 100W, built-in module, type AUPS-100-120-OFKEY FEATURES:

• a complete solution for powering CCTV devices in a small housing
• central power buffering
• long power supply time compared to classic systems using UPS power supplies
• low heating of the inside of the housing thanks to the high efficiency of the power supply
• easy installation in housings with system holes in a 10.8 mm pitch

The device is a buffer power supply designed to power CCTV devices or access control systems. The device is a convenient solution to the problem of buffer power supply for cameras and other monitoring devices requiring uninterruptible power supply. The power supply allows you to create distributed monitoring systems with centrally buffered power supply. The systems are designed to work with lead-acid or dry SLA batteries.OF (Open Frame) constructionallows the device to be installed in any housing, but the most convenient way of installation is dedicated ABOX series housings and mounting plates equipped with system holes in a 10.8 mm pitch. It is compatible with the spacing of mounting holes of built-in modules. The system solution allows for vertical or horizontal installation of selected devices in any part of the housing or mounting plate. TECHNICAL DATA:

Battery	1 x gel or AGM battery 12V / 7...18Ah
Output voltage	10,2 ... 13,8 VDC
Output current	8A
Power supply power	100 W
Efficiency	90% @100 W
Input voltage	190 ... 260 VAC, 50Hz
Battery charging current	1 A or 2 A (selected with jumper JP1)
Power supply input protection	3.15A slow-blow fuse
Power supply output protection	Mains power: Electronic overload protection at 9A (restart of the power supply required) Battery operation: 6.3A fuse
Battery circuit protection	Against reverse connection and overload: 6.3A fuse Against deep discharge: Battery disconnection for voltage below 10.2 V with automatic recovery
Signaling	LED1 (yellow) - presence of mains voltage LED2 (green) - presence of output voltage LED3 (red) - battery charging
Technical outputs	OUF – no voltage +DC_OUT ACF – no AC voltage Open collector outputs with a maximum load of 50mA (each output)
Start-up in the absence of AC power	Automatic startup of the power supply after connecting the battery
Housing design	None - built-in module
Installation	Snap-on spacer pins, mounting holes in 10.8 mm pitch
Operating temperature	-25 ... +50°C
Dimensions	65 x 118 x 45 mm
Libra	0,14 kg
