SigGen 3-in-1 FNIRSI DST-210 handheld digital multimeter with oscilloscope

SigGen 3-in-1 FNIRSI DST-210 handheld digital multimeter with oscilloscope

€89.09
Tax included
Quantity
Add to Wishlist
Add to Compare

  Security policy

(edit with the Customer Reassurance module)

  Delivery policy

(edit with the Customer Reassurance module)

  Return policy

(edit with the Customer Reassurance module)

FNIRSI DST-210 3-in-1 Handheld Digital Multimeter with Oscilloscope SigGen

The FNIRSI DST-210 is a new generation handheld digital multimeter that combines a True RMS multimeter, handheld oscilloscope, and DDS signal generator (SigGen) in one mobile device. Right from the start, it offers what classic meters lack: real-time waveform view, precise measurements up to 19,999 counts, data logging, trend analysis, and the ability to actively test circuits with a test signal. It is a complete tool for diagnostics, service, and field work.

A true handheld oscilloscope – full signal control

The built-in 10 MHz bandwidth oscilloscope with 48 MSa/s sampling allows you to observe signals with unprecedented detail in this class. Trigger functions, level adjustment, Auto/Normal/Single modes, and Infinite Afterglow make short disturbances, spikes, drops, or jitter immediately visible. This is a huge advantage in diagnosing power supplies, audio, LIN buses, PWM, or automotive electronics.

DDS generator for active circuit testing

The DST-210 is equipped with a DDS signal generator supporting 13 waveform types (

Easy-to-read screen in all conditions

The bright 2.8-inch TFT color display offers two themes: day mode (black on white) and night mode, so the device remains readable in full sunlight, at night, or in control cabinets. Large digits, graphs, MIN/MAX and RMS indicators—all visible at a glance.

Power and mobility without compromise

The built-in 3000 mAh battery, charged via USB-C, ensures long operating time and convenience of use. Programmable auto-off (15/30/60 min) saves energy, and a sturdy silicone cover protects the device from impacts and workshop conditions. This equipment is ready for field work.

Thoughtful ergonomics and classic operation

The iconic function knob combined with a modern interface makes operation quick and intuitive. Automatic range selection, logical menus, and physical buttons give you full control even when wearing work gloves. It's a combination of classic design and modern electronics.

Included:

FNIRSI DST-210P6100 oscilloscope probeTest leadsProbe with alligator clipsUSB cableUser manual

ManufacturerFINDModelDST-210Device type3-in-1 handheld digital multimeter: True RMS multimeter, oscilloscope, DDS signal generatorScreen2.8" color TFT display with day and night modesResolution19,999 countsOscilloscope10 MHz bandwidth, 48 MSa/s sampling, Auto/Normal/Single modes, Infinite Afterglow, Waveform HoldSignal generatorDDS, 13 waveforms, 0–50 kHz, amplitude 0.1–3.0 V, duty cycle 0–100%Voltage measurementDC up to 1000 V, AC up to 750 VCurrent measurementAC/DC up to 9.999 AOther measurementsResistance, capacitance, frequency, temperature, diode test, continuity test, Live/WirePower supply3000 mAh battery, USB-C charging, auto power off 15/30/60 minConstructionReinforced housing with silicone cover, intelligent overload protection
