- Application:Multifamily
- Connection type:Wired, two-wire
- Adaptation:bus to LAN
- Max. number of M05S modules in the bus:≤ 8
- Requires an additional power supply:So, 24 V to 4 A)
Genway F-M05S-2W - Network module for transmitting a 2-wire bus via LAN to the F series system
€229.42
Tax included
- Application:Multifamily
- Connection type:Wired, two-wire
- Adaptation:bus to LAN
- Max. number of M05S modules in the bus:≤ 8
- Requires an additional power supply:So, 24 V to 4 A)
Security policy
(edit with the Customer Reassurance module)
Delivery policy
(edit with the Customer Reassurance module)
Return policy
(edit with the Customer Reassurance module)
The module allows you to send a two-wire bus via LAN. The module has one RJ45 socket, which we connect to the switch, and two connectors for a two-wire bus. From the switch we output other F-M05S-2W modules to ensure communication between the modules. The module requires an additional DC 24 V power supply and simultaneously supplies DC 24 V power up to 4 A (depending on the power supply's current capacity) to the devices on the bus.
Technical data:
| Input power | DC 24V ≤ 4A (no polarity) |
| Output power to the main bus | DC 24 V ≤ 3.5 A |
| Output power supply to additional bus (e.g. external panel) | DC 24 V ≤ 0.5 A |
| RJ45 socket | 1 (works only with a switch) |
| Length of two-wire bus | ≤ 100m (optimum impedance 100 ~ 120 Ω) |
| Max. quantity of F-M05S-2W in one installation | ≤ 8, up to 100 m between the switch and the module |
| Power consumption in standby mode | ≤ 0,8 W |
| The ambient temperature at which the device can operate | -25 °C ~ 45 °C |
| Storage temperature | -30 °C ~ 60 °C |
| Dimensions | 90 x 53.5 x 58 mm (L x W x H) |
