- The cable is gelled; In the section: 200 m. The given price is for 1 m when purchasing the entire roll
- Coaxial cable: TRISET
- Inner core: Ø 1.13 mm Cu
- Dielectric: Ø 4.8 mm (physically foamed)
- Ekran:Al/PET/Al
TRISET-113PE/200 COAXIAL CABLE
€7.07
Tax included
- The cable is gelled; In the section: 200 m. The given price is for 1 m when purchasing the entire roll
- Coaxial cable: TRISET
- Inner core: Ø 1.13 mm Cu
- Dielectric: Ø 4.8 mm (physically foamed)
- Ekran:Al/PET/Al
Security policy
(edit with the Customer Reassurance module)
Delivery policy
(edit with the Customer Reassurance module)
Return policy
(edit with the Customer Reassurance module)
High-quality TRISET-113PE/200 coaxial cable dedicated to both individual and collective installations
It can be successfully used in DVB-T/T2 digital terrestrial television, FM/DAB radio and multiswitch systems (DVB-T/T2 terrestrial television and DVB-S/S2 satellite)
The cable is made of PE (polyethylene) sheath and is therefore intended for outdoor use
To facilitate work, a length mark is printed on the cable every 1 m
The cable was manufactured in compliance with strict quality requirements, with small permissible deviations from the nominal parameters.
The cable is gel-coated
| In the episode: | 200 m . The given price is for 1 m when purchasing the entire roll |
| Coaxial cable: | TRISET |
| Internal vein: | Ø 1.13 mm With Wire |
| Dielectric pressure: | Ø 4.8 mm (physically foamed) |
| Screen: | Al/PET/Al - 30 µm / 12 µm / 30 µm |
| Plot: | 81% Drut Al |
| Outer coating: | Ø 6.8 mm PE + gel |
| Coating Color: | Black |
| Conductor resistance for direct current: | 16.85 Ω/km |
| Capacity: | 52 pF/m |
| Insulation resistance: | 2000 MΩ/km |
| Wave contraction factor: | 84 % |
| Impedance: | 75 OH |
| Shielding effectiveness: | ≥ 90 dB @100-900 MHz |
| Minimum bending radius: | 35 mm |
| Selected features: |
|
| Libra: | 40 kg/km |
| Working temperature: | -30 °C ... 70 °C |
| Guarantee: | 5 lat |
