PoE adapter lowering voltage, Vin 13...56VDC, Vout 12VDC, Iout 1A, Pout 12W, compatible with PoE PASSIVE switches, RJ45/RJ45 connectors, ATTE type ASDC-12-120-HS
ATTE ASDC-12-120-HS voltage step-down PoE adapter
€96.00
Tax included
PoE adapter lowering voltage, Vin 13...56VDC, Vout 12VDC, Iout 1A, Pout 12W, compatible with PoE PASSIVE switches, RJ45/RJ45 connectors, ATTE type ASDC-12-120-HS
Security policy
(edit with the Customer Reassurance module)
Delivery policy
(edit with the Customer Reassurance module)
Return policy
(edit with the Customer Reassurance module)
PoE adapter lowering voltage, Vin 13...56VDC, Vout 12VDC, Iout 1A, Pout 12W, compatible with PoE PASSIVE switches, RJ45/RJ45 connectors, type ASDC-12-120-HS
The ASDC-12-120-HS adapter is a non-isolated DC/DC step-down converter. The device is powered by a 48 V PoE line and provides a stabilized output voltage of 12 V. In the ASDC-12-120-HS version of the adapter, the 12 V output voltage is available in the RJ-45 plug. The device can be powered by PoE PASSIVE switches.
KEY FEATURES:
- solution for powering WiFi devices requiring 12 V PoE voltage from a 48 V PoE line
- wide input voltage range
- small module size
| Supported PoE power supplies | PASSIVE PoE |
| Connectors | RJ-45 / RJ-45 - input / output voltage |
| Output voltage | 12 VDC +/-3% - PoE voltage on RJ-45 |
| Output current | 1A |
| Input voltage | 13 ... 56 VDC - PoE voltage on RJ-45 |
| Signaling | Red LED inside the RJ-45 socket - presence of output voltage |
| Housing design` | Insulating polyethylene foil |
| Degree of protection | IP20 |
| Operating temperature | -10 ... +40°C |
| Dimensions/weight | 75 x 21 x 17 mm / 0,015 kg |
