The AXON-PRO-IP-POE+ device is designed for surge protection of CCTV systems connected via a 10/100/1000 Mb/s Ethernet network and remotely powered using PoE+ technology
AXON-PRO-IP-POE+ SURGE LIMITER
€342.65
Tax included
The AXON-PRO-IP-POE+ device is designed for surge protection of CCTV systems connected via a 10/100/1000 Mb/s Ethernet network and remotely powered using PoE+ technology
Security policy
(edit with the Customer Reassurance module)
Delivery policy
(edit with the Customer Reassurance module)
Return policy
(edit with the Customer Reassurance module)
The AXON-PRO-IP-POE+ device is designed for surge protection of CCTV systems connected via a 10/100/1000 Mb/s Ethernet network and remotely powered using PoE+ technology
PoE+ technology allows you to power devices with increased power consumption, e.g. Speed Dome HD cameras
It protects each wire in a four-pair cable and discharges the electrical charge to the ground
It simultaneously protects the data transmission path and the power supply path
The use of a shielded RJ-45 socket allows for maintaining screen continuity when using an FTP cable
The condition for proper operation of AXON-PRO-IP-POE+ is to connect it to a functional grounding or PE protective conductor.
| Number of channels: | 1 |
| Rated voltage: | 120 V |
| Maximum voltage: | 150 V |
| Nominal supply current: | 600 mA |
| Line-to-ground protection voltage [C2]: | ≤ 1000 V - 1.2/50 µs |
| Nominal discharge current (line-ground) [C2]: | 2 kA - 8/20 µs |
| Protected wire pairs: | 1-2, 3-6, 4-5, 7-8 |
| Connector type: |
|
| Cable Length: | 0.23 m STP |
| Ground wire length: | 0.29 m |
| Case: | Metal, black |
| Libra: | 0.104 kg |
| Dimensions: | 50 x 40 x 30 mm |
| Guarantee: | 2 lata |
