Adapter POE Splitter 48V do 12V

➡️ The adapter is a useful tool in network installations that allows you to power devices via an Ethernet cable. Thanks to this solution, you can save space and time spent on installation, as well as reduce the amount of cabling.

☑️ If you have a PoE switch, thanks to this adapter you can do without additional power supplies and power e.g. 12V cameras using a PoE switch.

⭐ Main advantages ⭐

✅ Can be used in many different areas, e.g. IP cameras, access points, network devices (routers, modems), monitoring

✅ Allows you to power devices with 12V DC using a twisted pair

✅ The adapter adjusts the voltage within the range48-57V DCto value12V

✅ Equipped with 1 RJ45 port on input, Ethernet cable and DC power cable

✅ Can share power and data signal from network cable, making it applicable to devices that do not support PoE power supply

✅ Splitter provides protection against sudden power outage

✅ The adapter has circuit insulation protection

✅ Splitter provides stable and uninterrupted transmission (up to 100 meters)

✅ The device is water resistant thanks to additional covers that seal the connection

✅ The PVC material used for construction ensures the long life of the adapter

Wide range of applications and ease of installation ✔️

Due to its compact size and lightness, the POE adapter is an ideal solution for devices that do not have PoE power supply, such as access points (AP) or IP cameras.

It is perfect for hotel monitoring applications, campus networks, FTTH (fiber to the home) systems, security monitoring in enterprises, etc.

Thanks to the "plug and play" feature, the adapter is easy to install and use, making network management much easier.

High quality and water resistant ✔️

The adapter is highly resistant to moisture and is equipped with a gland that ensures durability and tightness of the connection. This allows for trouble-free outdoor use even in rainy conditions.

Thanks to the "plug and play" function, the adapter is easy to install and use, which significantly reduces implementation costs and facilitates network management.

The product is brand new, high quality and ensures effective POE signal conversion in an environment where devices do not support PoE.

ℹ️ Specification:

• POE Voltage:48-57V
• Output voltage:12V
• Output current:2A
• Power Mode:1/2(+) /3/6(-)
• Protocol compliance:IEEE802.3-AF/IEEE802.3-AT
• Maximum power:15.4W
• Transmission speed:10/100 Mbps
• Cable type:Category 5 and above, unshielded twisted pair
• Waterproof:Not
• Working temperature:-20°C - 60°C
• Operating humidity:0-90% (non-condensing)
• Adapter Length:19,5 cm

Product code: U012
