Устройство защиты Hager AD982J RCBO, 1P+N, 6kA, C-32A, 300mA, Тип A

The Hager AD982J is a combined residual current circuit breaker with overcurrent protection (RCBO) in a compact 2-module width. It offers 1P+N protection with a rated current of 32A, trip curve C, and a breaking capacity of 6kA. The integrated residual current device is Type A with a sensitivity of 300mA, providing protection against earth faults and overcurrents.

• 1P+N protection – single-pole switching with neutral protection
• 6kA breaking capacity – suitable for residential and commercial installations
• C-curve – for moderate inrush currents (e.g., motors, transformers)
• Type A RCD – detects sinusoidal AC and pulsating DC fault currents
• 300mA residual current – ideal for fire protection or circuits with high leakage
• 2-module width – saves space in distribution boards

Designed for DIN rail mounting, the Hager AD982J ensures reliable protection and compliance with standards. Suitable for use in residential and commercial electrical panels.
