Hager ADM432C RCBO 4P 6kA B-32A 30mA A tipas

The Hager ADM432C is a 4-pole RCBO (Residual Current Circuit Breaker with Overcurrent Protection) combining overcurrent and residual current protection in one compact device. Rated at 13A with a C-curve trip characteristic and 30mA Type A residual current sensitivity, it offers reliable protection against overloads, short circuits, and earth faults.

• 4-pole design for three-phase systems
• Breaking capacity: 6kA (Icn)
• Rated voltage: 230/400V AC, 50Hz
• Width: 4 DIN modules
• Mounting: DIN rail 35mm
• Terminal type: Screw terminals
• IP20 rated for indoor use

Ideal for distribution boards in residential and commercial installations, the Hager ADM432C ensures safety and compliance with modern electrical standards.
