Hager HXA005H Type 2 Surge Protective Device 380-450V AC 1P+N

Hager HXA005H Type 2 Surge Protective Device 380-450V AC 1P+N

Hager
53,13 €
Sisältää alv:n
Protect your electrical installation with Hager HXA005H Type 2 SPD. Rated 380-450V AC, 1P+N, 40kA Imax. Reliable surge protection for TN-S systems.
Delivery: 5 business days

The Hager HXA005H is a Type 2 surge protective device (SPD) designed for AC mains applications. It provides reliable protection against transient overvoltages in low-voltage distribution systems.

  • Type 2 SPD for AC mains (380-450V AC)
  • 1P+N configuration suitable for TN-S earthing systems
  • High discharge capacity: Imax 40kA (8/20µs), In 20kA
  • Low voltage protection level Up ≤ 1.8kV
  • Replaceable cartridge for easy maintenance
  • Compact 2-module DIN rail mount for space-saving installation

Ideal for protecting sensitive equipment in residential and commercial buildings. Ensure compliance with surge protection standards.

  • Tuotemerkki
  • Viite
    HXA005H
  • Varastossa
    800 Tuotteet
  • EAN13
    3250613346355
  • Valmistajan tuotenumero (MPN)
    HXA005H

  • Application
    AC mains
  • Mounting type
    DIN rail 35mm
  • Replaceable cartridge
    Yes
  • Brand
    Hager
  • Model
    HXA005H
  • SKU
    HXA005H
  • Product Type
    Surge protective device (SPD)
  • EAN
    3250613346355
  • Number of Poles
    1P+N
  • Ingress Protection (IP)
    IP20
  • SPD Type / Class
    Type 2
  • Earthing / Network System
    TN-S
  • Max Discharge Current (Imax, 8/20µs)
    40 kA
  • Impulse Current (Iimp, 10/350µs)
    12.5 kA
  • Nominal Discharge Current (In, 8/20µs)
    20 kA
  • Nominal Voltage (Uc)
    380-450V AC V
  • Voltage Protection Level (Up)
    1.8 kV
  • Mounting Width (DIN modules)
    2
  • Remote Signalling Contact
    No
