SOLAX CYQ946 Three-Phase Hybrid Inverter 100kW PV + Battery

SOLAX X3-FTH-100K Three-Phase Inverter 100kW

€8,811.84 (Save €6,032.54)
€2,779.30
Tax included
SOLAX X3-FTH-100K 100kW three-phase grid-tie inverter. 150kW DC input, 1100V, 9 MPPT inputs, 98.6% efficiency, data logging, DIN rail mount.

SOLAX X3-FTH-100K three-phase grid-tie inverter for commercial photovoltaic systems. High-efficiency conversion with 9 independent MPPT inputs and integrated DC switch for flexible solar array configurations.

  • Nominal output: 100 kW AC (3-phase)
  • Maximum input: 150 kW DC, 1100 V
  • 9 independent MPPT inputs (32 A each)
  • Maximum efficiency: 98.6%
  • European efficiency: 98.3%
  • Integrated DC switch and data logger
  • Dimensions: 327.5 × 985 × 660 mm
  • Weight: 83 kg

  • Reference
    CYQ946
