CHINT CHV629 RCBO 3P+N C32 30mA 6kA

CHINT CHV629 RCBO 3P+N C32 30mA 6kA Class A

CHINT
€103.66
Tax included
CHINT CHV629 combined RCBO, 3P+N, C32, 30mA, 6kA, Class A - all-in-one circuit and leakage protection. Order today.
Delivery: 5 business days

Notify me when available

Interested in this product? Drop us an email and we will let you know when it's available for order.

The CHINT CHV629 (NB310L series) is a combined RCBO that brings residual current (RCD) Class A protection together with overload and short-circuit protection in a single DIN-rail device.

  • 3P+N configuration rated at 32 A with a C trip curve.
  • 30 mA Class A residual current sensitivity.
  • 6 kA rated breaking capacity (Icn) to EN 61009-1.
  • Rated voltage 230/400 V AC, 50/60 Hz.
  • IP20 protection class, DIN-rail mounting.

A space-saving, all-in-one solution for circuits that need both overcurrent and earth-leakage protection.

  • Brand
  • Reference
    CHV629
  • EAN13
    6925808357696
