Interra ITR332-2801 iX1 2" KNX Touch Panel, 2-4-8 Button, Black with AQI

Interra iX1 is a compact 2-inch KNX touch panel for wall-mounted control in smart homes and offices, finished in black. This version adds a built-in air quality (AQI) sensor alongside temperature, humidity and brightness sensing, so the panel can also flag when a room needs ventilation. It is configurable with 2, 4 or 8 touch buttons, each with independent RGB LED feedback.

The panel handles switching, dimming, shutter/blind control and up to 64 programmable scenes, plus thermostat functions with 2-point, PWM or continuous PI regulation for heating and cooling. All models in the range share one ETS database, keeping commissioning consistent across a project.

• Configurable 2, 4 or 8 touch buttons with independent RGB LED feedback
• Built-in temperature, humidity, brightness and air quality (AQI) sensors
• Switching, dimming, shutter/blind and scene control (up to 64 scenes)
• Thermostat control via 2-point, PWM or continuous PI modes
• Configurable external inputs (analog or digital) via ETS
• Comfort, standby, economy and protection operating modes with weekly scheduling
