CHINT NB1 MCB 1P 16A B 6kA Circuit Breaker

CHINT NB1 MCB 1P 16A B 6kA Circuit Breaker

CHINT
2,92 €
Sisältää alv:n
CHINT NB1-63 miniature circuit breaker 1-pole, 16A, Type B. 6kA breaking capacity, 230V rated. Overload and short circuit protection for residential and commercial wiring.
On backorder

CHINT NB1-63 series circuit breaker is engineered for reliable overload and short circuit protection in electrical installations. The Type B characteristic is suitable for most residential and commercial loads. Available in both AC and AC/DC configurations with 6kA breaking capacity at 230V and excellent mechanical durability over extended service life.

  • 1 pole, 16A rated current
  • Type B trip characteristic
  • 6kA short circuit breaking capacity
  • 230V rated voltage
  • AC/DC compatible
  • Compact DIN module design

  • Tuotemerkki
  • Viite
    CFS005
  • EAN13
    6925808305369
  • Valmistajan tuotenumero (MPN)
    CFS005

  • Frequency
    50-60 Hz
  • Rated voltage
    230 V
  • Poles
  • Rated current
  • Power loss
    6 W
  • Characteristic
    B
  • Impulse withstand voltage
    4 kV
  • Insulation voltage
    500 V
  • Short circuit capacity (6kA)
    6 kA
  • AC/DC type
    AC/DC
